Kensol KTM 14 kW Monobloc Heat Pump with Energy Efficiency Class A+++ (W35)

The Kensol heat pump delivers 14 kW and features an integrated independent Panasonic DC Twin Rotary compressor. It represents a new, energy-saving solution, guaranteeing the highest energy efficiency class A+++ (W35) as well as high SCOP efficiency, while ensuring exceptionally quiet operation. The pump is backed by a five-year warranty provided by an authorized service in Poland.

By using the environmentally friendly R32 refrigerant in conjunction with inverter technology, efficient heating and cooling of the house is possible, and hot water preparation is also reliably achieved, even in extremely cold climates. The Kensol heat pump is characterized by a modern design and a mobile app for system control.

Increased user comfort is achieved through a central control system including a controller equipped with a 4.2-inch touchscreen, offering quick insights into pump parameters and remote control options. Thanks to its compact design and flexible installation options, the heat pump is ideal for homeowners as well as operators of shops, offices, or service buildings.

Technical Highlights at a Glance:

• Monobloc Design: Easy installation, as all components are integrated into one casing.
• Rated Heating Capacity: 14 kW, ideal for small to medium-sized residential homes.
• Environmentally Friendly R32 Refrigerant: Reduces environmental impact and contributes to sustainability.
• Panasonic DC Twin Rotary Compressor: Ensures high efficiency and long service life.
• EVI System (Enhanced Vapor Injection): Improves performance at low outdoor temperatures.
• High Energy Efficiency: A+++ (at W35), A++ (at W55) for low energy consumption.
• SCOP of 4.60: High seasonal performance factor for efficient operation throughout the year.
• Wide Operating Temperature Range: Works reliably from -30°C to 43°C.
• Maximum Operating Water Temperature: Up to 65°C, ideal for radiators and hot water preparation.
• Wi-Fi Connectivity: Allows control and monitoring of the heat pump via a mobile app.
• Smart Function for Energy Management Systems: Optimizes energy consumption in conjunction with PV systems.
• SG Ready Technology
• Five Operating Modes: Silent, Powerful, schedule control, weather control, operation from room thermostats for optimal comfort.
• Frost Protection: Protects the outdoor unit and heat exchanger from frost damage.
• Warranty: 5-year product warranty

Technical Data:

• Heating Mode (7/6 °C, 30/35 °C)
• Heating Capacity (kW) 5.9 – 18.2
• Power Consumption (kW) 1.20 – 4.11
• Rated Operating Current (A) 1.86 – 6.37
• COP 4.43 – 4.92
• Cooling Mode (35/24 °C, 12/7 °C)
• Cooling Capacity (kW) 3.81 – 11.53
• Power Consumption (kW) 1.11 – 4.05
• Rated Operating Current (A) 1.72 – 6.28
• EER 2.85 – 3.43
• Hot Water Mode (20/15 °C, 15/55 °C)
• Heating Capacity (kW) 4.8 – 14.72
• Power Consumption (kW) 1.17 – 4.60
• Rated Operating Current (A) 1.82 – 7.15
• COP 3.2 – 4.1
• General Data
• Power Supply 380 V / 3 Phase / 50–60 Hz
• Energy Class (W35°) A+++
• Energy Class (W55°) A++
• Compressor Panasonic DC Twin Rotary
• Operating Range (°C) -30 – 43
• Max. Water Temperature (°C) 60
• Refrigerant R32
• Sound Power Level (dB(A)) < 57
• Water Connection DN25 (GZ)
• Casing Dimensions (W×D×H mm) 1050 × 480 × 1330
• Packaging Dimensions (W×D×H mm) 1100 × 530 × 1470
• Net/Gross Weight (kg) 170 / 180
• Warranty 5 Years

Scope of Delivery

• Kensol KTM14KW
• Operating Manual


Condition

New – original packaging

Shipping

• Freight forwarding throughout Europe
• Collection possible by arrangement

Important note!

Installation and commissioning of the devices must be carried out exclusively by specialist personnel. In the event of a complaint, professional installation/fitting by qualified specialist companies (specialist contractor certificate and special qualification) must be demonstrated. If no proof is provided, all warranty and guarantee claims will be void.

Technical changes and errors reserved! Prior sale reserved! Illustration similar!

Refrigerant leaks contribute to climate change. Refrigerants with a lower global warming potential (GWP) contribute less to global warming in the event of a leak than those with a higher GWP. A leak of 1 kg of this refrigerant would therefore have a greater impact on global warming, proportional to the refrigerant's GWP value, than 1 kg of CO2, over a period of one hundred years. Do not attempt any work on the refrigeration circuit or disassemble the unit – always consult qualified personnel.
