Midea
Air conditioner Midea BreezelessE 2x 2.8 kW MSCB1BU-09HRFN8-ME Dual Split Wall Unit WIFI
Air conditioner Midea BreezelessE 2x 2.8 kW MSCB1BU-09HRFN8-ME Dual Split Wall Unit WIFI
Price incl. VAT.
Delivery time on request
Out of stock
Product informations
"Air conditioner Midea BreezelessE 2x 2.8 kW MSCB1BU-09HRFN8-ME Dual Split Wall Unit WIFI "
| Data sheet | Download PDF |
|---|---|
| Installation instructions | Download PDF |
| Investment book | Download PDF |
Air Conditioner Midea BreezelessE Dual-Split Wall Unit SET 2x 2.79 kW MSCB1BU-09HRFN8-ME-Set R32 A++/A+
Equipped with the latest intelligent learning algorithm, the Midea BreezelessE can proactively calculate various options for better air conditioning and energy savings. It offers a comprehensive, comfortable experience through Breezeless cooling, powerful heating, Air Magic+ sterilization, and over-the-air technology for updates.
Intelligent energy-saving technology
The latest intelligent algorithm can proactively detect changing environmental factors every 30 seconds and adjust the temperature for additional energy savings of up to 20%.
Breezeless cooling comfort
5,013 miniature holes with an hourglass pattern ensure gentle cooling of the air. 6.3°C within 10 minutes.¹
Fast heating as a heat pump
Instantly warms in cool weather down to -2°C. Heats the air to 10.4°C within 10 minutes.²
Excellent performance from Midea:
Fresh air quality with Midea filter technology
Technical data:
Model Name: MSCB1BU-09HRFN8-ME + MSCB1BU-09HRFN8-ME + M2O-18HFN8-ME
Weight in kg: 54.2
GPSR Product Type: Bundle
GPSR Notice: Use this product only as intended. Installation/maintenance by qualified personnel. Observe manufacturer's instructions and regulations. Read the operating instructions. Contact a qualified specialist if you have any questions.
GPSR Link: Safety Information
GPSR referrer: ThermoFLUX Deutschland GmbH
GPSR address: Friedrich-Naumann-Str. 55, 99974 Mühlhausen
GPSR email: info@klimaworld.com
WEEE Reg. No. DE: 55703080
Number of indoor units: 2
Indoor unit type: Wall unit
MSCB1BU-09HRFN8-ME: BTU 9000
Cooling capacity: 2.79 kW (1.02 - 3.52)
Heating output: 2.93 kW (1.02 - 3.81)
Dimensions (W×H×D): 812 × 299 × 199 mm
Weight: 9.1 kg
Cooling air flow: max. 510 m³/h
Sound pressure level: 20.5 / 37 dB(A)
Max. sound power level cooling: 53 dB(A)
Power supply: 230 V / 1 Ph / 50 Hz
Pipe size fl. side: 1/4 inch / 6.00 mm
Pipe size gas side: 3/8 inch / 10.00 mm
Condensate connection: OD 16 mm
Cooling air flow: max. 510 m³/h
Sound pressure level: 20.5 / 37 dB(A)
Max. sound power level cooling: 53 dB(A)
Power supply: 230 V / 1 Ph / 50 Hz
Pipe size (bottom side): 1/4 inch / 6.00 mm
Pipe size gas side: 3/8 inch / 10.00 mm
Condensate connection: OD 16 mm
Remote control included: Yes
Remote control type: Infrared remote control
Outdoor unit: M2O-18HFN8-ME
Width of outdoor unit: 800 mm
Height of outdoor unit: 554 mm
Depth of outdoor unit: 333 mm
Weight of outdoor unit: 36 kg
Power supply cable outside: 3 × 2.5 mm²
Sound pressure level outdoor unit cooling/heating: 56 dB(A)
Maximum total cable length: 40 m (max. 25 m per indoor unit)
Maximum height difference: 15 m
Refrigerant / GWP: R32 / 675
Refrigerant basic filling quantity / CO² equivalent: 1.3 kg / 0.8775 t
Refill quantity: 12 g/m (Applies from 6 meters, as the outdoor unit is pre-filled up to 5 meters)
Cooling operating limit: -15 °C to 50 °C
Heating operating limit: -15 °C to 24 °C
Functions: Comfort Anti-Cold Air, Follow Me, Automatic Cooling-Heating Operation, Frost Protection, Auto-Restart, Sleep Mode
Functions: Health Air Filter, Self Cleaning, Ionizer, Coated Heat Exchanger
Functions: Breezeless airflow, 3D airflow, position memory, 12 fan speeds
Functions: Wireless Control, Timer
Additional functions: Dust Away, Winter Control, Refrigerant Monitoring, Self-Diagnosis, Diamond Design, Ventilation Only, Two-Way Connection, 1W Standby, Emergency Operation
Optional functions through accessories: cable remote control, remote on/off, fault message
Subject to technical changes and errors! Subject to prior sale! Illustration similar!
Note: The air conditioner may only be installed by a company certified under Regulation (EU) No. 517/2014 of the European Parliament and of the Council of April 16, 2014, on fluorinated greenhouse gases. By purchasing a split air conditioner, you confirm that it has been professionally installed by certified specialists. Refrigerant leaks contribute to climate change. Refrigerants with a lower global warming potential (GWP) contribute less to global warming in the event of a leak than those with a higher global warming potential (GWP). A leak of 1 kg of this refrigerant would therefore have a greater impact on global warming than 1 kg of CO2 over a 100-year period, proportional to the refrigerant's GWP value. Do not perform any work on the refrigerant circuit or disassemble the unit – always consult qualified personnel.
Midea Europe GmbH Ludwig-Erhard-Straße 14, Eschborn, 65760, Hesse, DE info-meg@midea.com 0619690200
