Midea Multisplit Inverter Outdoor Unit M4O-36FN8-Q 10.55 kW for 1-4 Indoor Units / Wall Units

Technical data:

Manufacturer: Midea
Outdoor unit model name: M4O-36FN8-Q
Outdoor unit dimensions in mm (WxHxD): 946 x 810 x 410
EAN: 4048164881079
WEEE Reg. No. DE: 55703080
BTU: 36000
Cooling capacity: 10.55 kW
Heating output: 10.55 kW
Cooling capacity (min. - max.): 2.05 kW - 10.55 kW
Heating output (min. - max.): 2.34 kW - 10.55 kW
BTU: 36000
Outdoor unit volume (max, in dB(A)): 63
Cooling power consumption: 3600 W (1250-3600)
Heating power consumption: 3000 W (1375-3360)
Cooling/heating operating range in °C: -15°C to -50°C / -15 to +24
Weight: 68.8 kg
Connectable indoor units (number): 1-4
Max. total cable length system: 80 m
Pipe length AG – IG Max.: 35 m
Height difference IG – AG Max.: 15 m
Refrigerant / GWP: R32 / 675
Refrigerant pre-charge (m): 5 m
Refrigeration line diameter liquid / gas: 4x 1/4" (6.35 mm) - 1x 1/2" (12.7 mm) - 3x 3/8" (9.52 mm)
Maximum total cable length: 80 m (max. 35 m per indoor unit)
Maximum height difference: 15 m
Refrigerant basic filling quantity / CO² equivalent: 2.1 kg / 1.4175 t
Refill quantity: 12 g/m (Applies from 6 meters, as the outdoor unit is pre-filled up to 5 meters)
Power supply (V/Hz/Ph): 220-240 , 220-240 | 50 | 1
Current – 50 Hz Max. fuse amperage: 20 A
Number of rooms: 2 rooms, 3 rooms, 4 rooms and more, 1 room
Device type: Cooling and heating
Device type: outdoor unit
Building type: House, Practices, House | Apartment, Practices | Office | Law Firm | Agencies
Total area: 91 m² -100m²
Cooling capacity range: 10.5 kW – 11.4 kW
Heating output range: 10.5 kW – 11.4 kW
Operating limit cooling -15 °C to 50 °C
Heating operating limit -15 °C to 24 °C

Note: The air conditioner may only be installed by a company certified under Regulation (EU) No. 517/2014 of the European Parliament and of the Council of April 16, 2014, on fluorinated greenhouse gases. By purchasing a split air conditioner, you confirm that it has been professionally installed by certified specialists. Refrigerant leaks contribute to climate change. Refrigerants with a lower global warming potential (GWP) contribute less to global warming in the event of a leak than those with a higher global warming potential (GWP). A leak of 1 kg of this refrigerant would therefore have a greater impact on global warming than 1 kg of CO2 over a 100-year period, proportional to the refrigerant's GWP value. Do not perform any work on the refrigerant circuit or disassemble the unit – always consult qualified personnel.
