Ultra-high energy efficiency

The Midea Oasis Plus series is equipped with ultra-high energy efficiency technology. Enjoy comfortable temperatures year-round while significantly reducing energy consumption.

The heat exchanger with a hybrid tube design of Φ7 and Φ5 offers 10% better performance than conventional heat exchangers.

The leading energy-efficient compressor is the core element of this technology.

An optimized air outlet design contributes to energy efficiency.

Heating and cooling at low ambient temperatures

The advanced inverter technology is designed to withstand even the most extreme weather conditions, ensuring comfortable heating and cooling performance even at outdoor temperatures as low as -30°C.

Thanks to the low-temperature cooling function, the speed of the outdoor fan can be adjusted according to the condenser temperature, so that the air conditioner operates smoothly even at outdoor temperatures as low as -15 °C.

Airflow

Oasis Plus guarantees first-class comfort: Warm air spreads right down to your toes, giving any room a spring-like atmosphere. Cool air is distributed evenly up to the ceiling, creating a harmonious feeling of freshness throughout the room.

Display with light sensor

The unit has a built-in light sensor that detects ambient brightness. When the light is turned off, the display gradually adjusts and dims, saving energy and allowing you to sleep comfortably.

Comfortable humidity

Intelligent sensor technology measures not only the temperature but also the humidity of the room. Using the Midea SmartHome app, you can set your personal optimal humidity level, which is adjustable from 30% to 90%.

Further specifications

product

• ModelOasis Plus
• Model number: MSOPBU-12HRFN8-ME / MOX333-12HFN8-ME

Specifications

• Cooling power consumption [W]483~748
• Heating power consumption [W]834~924
• Operating current (cooling) [A]2.1~3.25
• Air volume indoor unit [m³/h] 340/497/575
• Sound pressure level [dB (A)] 21/24/34/43
• Dimensions WxDxH [mm] Indoor unit 895x248x298
• Dimensions of outdoor unit (W x D x H) [mm]805x330x554
• Weight [kg] Indoor unit12.7
• Weight [kg] Outdoor unit 32.3
• Power supply (V/Ph/Hz) 230/1/50
• Pipe connections Liquid flow [mm (inch)]6.35 (1/4)
• Suction line pipe connections [mm (inch)]9.52 (3/8)
• Condensate pipe connections [mm (OD)]16

Subject to technical changes and errors! Subject to prior sale! Illustration similar!
